Plate DETAILS

AWP water-washable CTP

AsahiKASEI Digital plate-CTP

◆ washes and prints at once.
◆ Prepare time less than 1 hour
◆ Plate expression:
1) Dots average
2) Small dot slope is small
3) Anti-white line depth (line width:300μm, depth:280μm)
4) Isolated dot (dot width : 180μm, depth : 200μm)

Model: Click the Catalogue for more details.

Category: Plate

Tags: flexo plates, CTP plate, Digital flexo plates CTP, plate-CTP Flexo plate, AWP water-washable CTP

Share on:

Water-washable CTP :
AWP - DEF 1.14 : Thickness 1.14mm, Narrowest line 80μm mm, Hardness 77 (shore D), K-factor 5.98, Isolated dot 150μm, Dots reproduction (175L) 1 – 98%.
AWP – DEF 1.70 : Thickness 1.70mm, Narrowest line 80μm mm, Hardness 70 (shore D), K-factor 5.89, Isolated dot 150μm, Dots reproduction (175L) 1 – 98%.
Conventional solvent:
AFP – SH : Thickness 1.14 / 1.70 / 2.54 / 2.72 / 2.84 mm, Narrowest line 80μm mm, Hardness 77 / 69 / 63 (shore D), Isolated dot 150μm, 1% dot, 150lpi.
AFP – SF : Thickness 1.14 / 1.70 / 2.54 / 2.84 mm, Narrowest line 80μm mm, Hardness 74 / 62 / 56 / 54 (shore D), Isolated dot 150μm, 1% dot, 150lpi.

Click the Catalogue for more details

  • Click the Catalogue for more details

    Catalogue AsahiKASEI_DM.pdf download on Dec 2018
